Sunny Boy SB10000TL-US Inverter

Availability: Call For Availability

Quick Overview

  • Maximum efficiency of 98.3%

  • Transformerless, with H5 topology

  • Superior yield with OptiTrac MPP tracking

  • OptiCool™ active temperature management

  • SMA Power Balancer for three phase grid connection

  • Integrated DC load disconnect and combiner box

  • UL 1741/IEEE-1547 compliant

The new Sunny Boy SB10000TL-US is UL-listed for North America and features SMA’s innovative H5 topology, resulting in superior efficiencies of up to 98 percent and unmatched solar yields. The transformerless design reduces weight, increases the speed of payback and provides optimum value for any decentralized, commercial PV system. The Sunny Boy SB10000TL-US for North America is the ideal choice for mid-size and large plants from 24 kWp up to the megawatt range.

SMA Sunny Boy SB10000TL-US Inverter

Double click on above image to view full picture

Zoom Out
Zoom In


Model Number SB10000TL-US
AC Nominal Power (W) 10000.0
Peak Efficiency 0.983
CEC Weighted Efficiency 0.975
Weight (lbs) 77.0
Height (in) 24.0
Width (in) 18.5
Depth (in) 9.0

Manufacturer Specification Sheets

View FileSunny Boy TL-US Data Sheet    Size: (314.59 KB)


sunny boy SB10000TL inverter




Inverter Specifications

Sunny Boy SB10000TL-US Inverters Specifications

Efficiency Curve

Sunny Boy SB10000TL-US efficiency curve


SMA Sunny Boy  SB10000TL-US Accessories
