Sunny Boy SB8000TL-US Inverter

Availability: Call For Availability

Quick Overview

  • Maximum efficiency of 98.3%

  • Transformerless, with H5 topology

  • Superior yield with OptiTrac MPP tracking

  • OptiCool™ active temperature management

  • SMA Power Balancer for three phase grid connection

  • Integrated DC load disconnect and combiner box

  • UL 1741/IEEE-1547 compliant

The Sunny Boy SB8000TL-US inverter is UL-listed for North America and features SMA’s innovative H5 topology, resulting in superior efficiencies of up to 98 percent and unmatched solar yields. The transformerless design reduces weight, increases the speed of payback and provides optimum value for any decentralized, commercial PV system. The Sunny Boy SB8000TL-US grid-tie inverter for North America is the ideal choice for mid-size and large plants from 24 kWp up to the megawatt range.

Sunny Boy SB8000TL-US Inverter

Double click on above image to view full picture

Zoom Out
Zoom In


Model Number SB8000TL-US
AC Nominal Power (W) 8000.0
Peak Efficiency 0.983
CEC Weighted Efficiency 0.980
Weight (lbs) 77.0
Height (in) 24.0
Width (in) 18.5
Depth (in) 9.0

Manufacturer Specification Sheets

View FileSunny Boy TL-US Data Sheet    Size: (314.59 KB)


Sunny Boy SB8000TL-US Inverter




Inverter Specifications

SMA Sunny Boy SB8000TL-US Specifications

Efficiency Curve

SMA Sunny Boy SB8000TL-US efficiency curve


SMA Sunny Boy SB8000TL-US Accessories
