Model Number KD245GX-LPB
STC Rating 245.0
PTC Rating 219.1
Open Circuit Voltage (V) 36.9
Short Circuit Current (A) 8.91
Frame Color Black
Origin US/Mexico
Power % ± -3/5
(W/ft²) 13.83
Area (ft²) 14.6
Weight (lbs) 46.3
Length (in) 65.43
Width (in) 38.98
Height (in) 1.80

Kyocera KD245GX-LPB Solar Panels

Cutting Edge Technology
As a pioneer with over 35 years in the solar energy industry, Kyocera demonstrates leadership in the development of solar energy products. Kyocera’s Kaizen Philosophy, commitment to continuous
improvement, is shown by repeatedly achieving world record cell efficiencies.

Quality Built In
• UV stabilized, aesthetically pleasing black anodized frame
• Supported by major mounting structure manufacturers
• Easily accessible grounding points on all four corners for fast installation
• Proven junction box technology with 12 AWG PV wire to work with transformerless inverters
• Quality locking MC4 plug-in connectors to provide safe and quick connections

• Proven superior field performance
• Tight power tolerance
• Only module manufacturer to pass rigorous long-term testing performed by TÜV Rheinland

  • Kyocera standard 20 year power output warranty and 5 year workmanship warranty applies in USA
  • Extended warranties available per project requirements
  • Kyocera standard 20 year power output warranty and 2 year workmanship warranty applies outside of USA
  • Refer to Kyocera warranty policy for details
