20 Watt 12VDC 36Ahr Pole-Mounted Solar Panel System

Availability: Call For Availability


remote off-grid battery enclosure solar system
remote off-grid solar panel systems
MAPPS off-grid enclosure solar system logo

Pole Mounted Solar Panel Systems

20 Watt 12VDC 36Ahr Pole-Mounted Solar Panel System

one solar panel system
Enclosure solar system designed for long life in harsh weather climates.

Rugged Weatherproof Design

This highly reliable, durable, and rugged one-battery system is designed to require minimal maintenance with a 20 year design life (with battery replacements approximately every five to seven years). Our systems are assembled and tested following strict QA/QC procedures, and are designed to IEEE Standard 1562: Guide for Array and Battery Sizing in Stand-Alone Photovoltaic (PV) Systems.

MAPPS enclosure off-grid solar systems include components with the highest quality standards and qualify for Made in USA, Buy America and ARRA. MAPPS systems are also available with UL Listing or Class I Div II approval.

20W Pole Mounted Solar Panel System w/ 1 battery

charge controller Charge control load center with pre-cut color coded wiring harness included.
lock for battery box
enclosure box lockable latch
The compression latch for locking includes a 5/16" and 1/4" shackle.
charge controller options
We can pre-wire many options.

Solar Panel

  • High efficiency crystalline silicon
  • Meets JPL Block V durability criteria
  • Tempered glass and aluminum frame
  • Conduit ready junction box or MC 4 connectors

Gel Cell Sealed Battery

  • Sealed maintenance-free
  • Excellent deep-cycling performance
  • Immobilized electrolyte, non-spillable
  • Transports easily and safely

System Enclosure

  • Mill finish Aluminum construction
  • Powder coated enamel white option
  • Filtered louvered vents
  • Insulation Kit for battery optional
  • Controller mounted on DIN rail with array/battery/load breakers

Balance of System Components

  • Heavy duty aluminum mounting structure
  • Controller with low voltage battery protection
  • Optional 130 and 170 MPH available
  • Color-coded, pre-cut wiring harness
  • Easy-to-follow manual/system schematics

Optional Components

  • DC to DC converters for 12, 24, 48 VDC loads
  • DC to AC inverter for 120 VAC loads
  • Radio shelf for additional load equipment
  • Pre-wired PoE Power over Ethernet injectors
solar contractors on utility transmission tower

MAPPS Remote Pole-Mounted Solar Power System Applications

No matter what extreme environment on Earth: arctic, desert, coastal or tropical, this corrosion-resistant solar power system is ideal for your next remote off-grid solar project.

Solar battery powered examples can include:

  • Wifi cameras
  • Weather stations
  • RFID
  • LED lighting
  • ControlWave Micro and Cards
  • Raven RV50 (Idle)
  • Rosemount PITs
  • Solenoid Valves
  • Contact us with your solar powered application today! OEM, Distributor, System Integrator, Government, VAR, Dealer, Contractor, MWBE, International, and Reseller discounts available.

    Call toll-free: (877) 297-0014

    20 Watt 12VDC 36Ahr Pole-Mounted Solar Panel System

    Double click on above image to view full picture

    Zoom Out
    Zoom In


    SES MAPPS Off-Grid Solar Panel System

    Model Number MAPPS-20-36-12
    Nominal System Voltage 12 VDC
    Solar PV Module

    SES 420J 12 Vdc 20 Watts

    Solar Module Certifications UL 1703, Class C Fire Rating
    PV Module Mount HPM-10/20/30 side of pole mount
    Battery Type Deka Solar 8GU1 Gel Cell
    Battery Capacity 12V 36 Ahr at 100 hour discharge rate
    Enclosure Model AL-POL-1-G31N
    Enclosure Rating NEMA 3R
    Charge Controller SunSaver SS-10L-12
    Controller Certifications ETL Listed to UL 1741 & CSA C22.2 No. 107.1-01
    MAPPS System Weight w/ Batteries 60.6 lbs.
    Origin USA
    List Price $1,303.52
    UL Listed C US
    Optional UL Listing Available

    Manufacturer Specification Sheets

    View FileMAPPS 20-36-12 Pole-Mounted Battery Enclosure Solar System Datasheet    Size: (131.83 KB)
    View FileMAPPS Solar Panel System Design Guide    Size: (317.13 KB)


    MAPPS 20W 36AHr Battery Pole-Mounted Enclosure Solar Panel System Review

    pole mounted one battery enclosure solar system
