Aquion 48S-2.2 saltwater battery specifications
Aquion Energy Model Number Aspen 48S-2.2
Nominal Battery Voltage 48 Volts
Nominal Capacity 2.2 kWr
(20 hr. rate)
Cycle Life 3,000 Cycles
(to 70% retained capacity)
Voltage Range 40.0 - 59.5 Volts
Peak Power 1.0 kW
Height 36.8 in.
Width 13.0 in.
Depth 12.2 in.
Weight 260 lbs.

Aquion Energy Aspen 48S-2.2 AHI Battery

SKU 48S-2.2
Aquion Energy logo

Aquion Energy emerged from Chapter 11 US Bankruptcy Protection
and will be releasing a new product once restructuring is complete and new battery chemistry has been perfected.



Aquion Energy Aspen 48S-2.2 AHI Saltwater Battery

Aqueous Hybrid Ion (AHI™) energy storage system battery.

The Aquion Aspen 48S-2.2 battery is a clean, 48 Volt, saltwater battery that outperforms and outlasts traditional lead acid batteries. Aquion’s proprietary Aqueous Hybrid Ion (AHI) technology uses no heavy metals or toxic chemicals and is non-flammable and non-explosive, making Aquion batteries the safest and most sustainable in the world. These batteries are used in the plug-and-play Aspen 48M-25.9 battery bank.

large quantity Aquion batteries
Aquion Aspen 48S-2.2 AHI saltwater batteries are made in the USA and available in large or small quantities at low wholesale prices. Contact us

Aquion 48S-2.2 Benefits

Reliable

  • Avoid costly downtime and battery replacements
  • Tolerant to high ambient temperatures
  • 100% DoD cycling with minimal degradation
  • Self-balancing, minimal self-discharge, and no trickle charge required
  • High tolerance to long stands at partial state of charge (PSOC)

Safe

  • Safe to handle, ship, and operate
  • Non-flammable, non-toxic, and non-explosive
  • No dangerous or catastrophic failure modes
  • Eliminates high concentrations of toxic or flammable materials, critically important for large scale urban installations

Cost Effective

  • Excellent calendar and cycle life
  • No thermal management or active battery management system required
  • Straightforward site preparation and installation
  • Simple system operation
  • Minimal system maintenance

Sustainable

  • Environmentally friendly
  • No hazardous or toxic materials
  • Recyclable and land-fill safe
  • Cradle to Cradle Certified™ Bronze

The Aquion 48S-2.2 battery is very robust in a partial state-of-charge cycling state and a wide range of ambient temperatures. Aspen batteries are ideal for energy storage applications that limit the life, performance, or safety of traditional battery technologies.

Aquion Aspen 48S-2.2 Battery Review



energy storage load balancing
Aquion 48S batteries are ideal for utility grid-tie
energy storage for load balancing.

Aquion Aspen 48S-2.2 AHI Energy Storage Battery Review

Aquion’s Aspen 48S-2.2 is simple to configure and install and requires no maintenance. This battery is abuse tolerant and can handle wide temperature ranges. It can be left at partial states of charge without degradation and sulfation.

Thousands of cycles and deep cycling capability means greater usable energy which results in competitive up-front costs and little or no maintenance costs. The combination of performance, affordability, safety, ease of use, and sustainability makes the Aquion Aspen 48S-2.2 battery ideal for solar energy and other energy storage systems.

Aquion Aspen batteries are the first and only in the world to be Cradle to Cradle Certified™, an esteemed quality mark for products made from sustainable materials and manufacturing processes. These batteries are elgible for LEED Credits and feature a full LEED Material Ingredient Disclosure.

More Aquion Batteries

Aquion 48M-25.9 Battery Bank w/ 12 48S-2.2 AHI batteries also available.

hybrid microgrid battery module system

With decades of experience, Solar Electric Supply has the friendly, knowledgeable staff for just about any large energy storage system project.

Contact us for expert energy storage system design.



This AHI energy storage battery is ideal for powering telecommunications, island power, cellular radio, microgrid, remote wi-fi, solar farms, wind farms, railroad signs/communication, remote residential, grid-tie battery backup and uninterruptible power sources (UPS).

VIEW SOLAR BATTERIES


Contact us for wholesale pricing on equivalents for the Aquion 48S-2.2 battery.
