Quick Mount PV Classic Composition

Quick Mount PV Classic Composition Mount

Quick Mount PV Classic Composition Mount
Available in Mill or Bronze Anodized Finishes Item Code: QMSC

We proudly provide Quick Mount PV's best-selling mount for rooftop installations of PV and solar water heating systems. The Quick Mount PV Classic Composition Mount uses Qblock Elevated Water Seal technology to ensure a long, watertight life on composition/asphalt shingle roofs.

The Classic Comp was also designed to install fast,
with just a single bolt and is the most universally code-compliant
mount available for composition/asphalt roofs.

MFG Page: Quick Mount PV. Respect The Roof.

Classic info Classic Composition Mount Specification Sheet

Comp roof info Know Your Composition Roof Tutorial

Quick Mount Flashing

Classic Composition Mount Features:
  • Stainless steel hardware (included)
  • 10-Year Warranty; 50-Year Expected Life
  • Works with all leading racks
  • Won't void roof manufacturers warranty
  • Approved for use by leading roof manufacturers
  • Meets or exceeds roofing industry best practices
  • 2554 lbs. average pullout (douglas fir); 2203 lbs. average shear
  • ICC-ES Certified ICC-ES Certified ICC-ESR-2835
  • One bolt installation
  • No shingle cutting
  • 100% IBC Compliant
  • Patent Numbers 7,762,027 & 7,895,808


Made In USA Made In USA

There's no need for trimming shingles to force a fit. Drill one pilot hole into the rafter, backfill it with appropriate sealant, slide the Quick Mount flashing beneath the course above, drive the bolt home and it's done.

The 12 X 12 inch Classic Composition Mount flashing is designed to fit within a standard 5 to 5.5" course and the exposed course should be no greater than 5.75". If the exposure is greater than this, use the Classic Shake Mount as an alternative. There's no shingle cutting and no shingle distortion caused by trying to force a fit. Just a permanent, watertight mount every time!

PV, Solar Water Heating and More
The Quick Mount PV Classic Composition Mount is the logical choice not only for solar PV installation, but also for rooftop solar water heating systems. In fact, whatever you need to fasten to a composition roof - HVAC equipment, antennas, satellite dishes - use Quick Mount PV to secure and protect every roof installation you put your name on. Ontario Domestic Content Compliant

The Classic Composition Mount is also made by Quick Mount PV Canada in Ontario, Canada and meets the OPA Ontario Feed-in Tariff program's requirement for domestic content.

ICC-ES certification pending in Canadian production
Made In Canada Made In Canada
